Placa de baza Gigabyte GA-H61M-DS2 LGA1155, DDR3,

Descriere

Se vinde placa de baza si tablita, fara alte accesorii

Produsul este second hand, testat, stare perfecta de functionare

Pozele sunt informative

Garantie 12 luni

Procesoare suportate: Intel Core i7 /Intel Core i5 / Intel Core i3 /Intel Pentium /Intel Celeron
Socket: LGA1155
Intel H61 Express Chipset
Memorie suportata::
2 x 1.5V DDR3 DIMM sockets
Memorie maxima RAM: 16GB
Dual channel
DDR3 2200(OC)/1333/1066/800 MHz non-ECC
Support for Extreme Memory Profile (XMP) (Ivy Bridge only)

Onboard Graphics: Integrated Graphics Processor
1 x D-Sub port

Audio:
Realtek ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel

LAN: Realtek GbE LAN chip (10/100/1000 Mbit)
Expansion Slots:
1 x PCI Express x16 slot, running at x16 3.0 standard
2 x PCI Express x1 slots

Storage Interface: Chipset:
4 x SATA II 3Gb/s

USB: Chipset:
Up to 8 USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

Internal I/O Connectors:
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
2 x USB 2.0/1.1 headers
1 x Clear CMOS jumper

Back Panel Connectors:
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x D-Sub port
1 x parallel port
1 x serial port
4 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks (Line In/Line Out/Microphone)
I/O Controller:
iTE I/O Controller Chip
H/W Monitoring:
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU/System fan speed control

BIOS:
2 x 32 Mbit flash
Use of licensed AMI EFI BIOS
Support for DualBIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a
Unique Features:
Support for BIOS
Support for Q-Flash
Support for EasyTune

Form Factor:
Micro ATX Form Factor; 22.6cm x 17.4cm
